| Welding current adjustment range | 3A - 300A |
| Duty cycle 40 °C | 300A / 40% |
| 270A / 60% | |
| 220 A / 100 % | |
| Open circuit voltage | 87 V |
| Mains voltage (from factory) | 3 x 380V - 400V |
| Mains tolerance (from factory) | -25 % to +20 % |
| Mains frequency | 50Hz/60Hz |
| Recommended generator power | 15.3 kVA |
| Power consumption Pi | 21 W |
| Protection class | IP23 |
| EMC class | A |
| Dimensions (L x W x H) | 550 mm x 257 mm x 415 mm |
| Weight | 20.5 kg |
| Standards | IEC 60974-1, -3, -10 CL.A |
