Loctite 5910 Ultra Black Gasket Maker - 100 ml

Loctite 5910 Ultra Black is a replacement for cork and paper die-cut gaskets on flanges. It is recommended in cases where strong vibrations or flexing of the sealed parts occur. It can also be used on plastic and painted components.

Typical applications for Loctite 5910 Ultra Black include covers made from steel sheets (distributor covers and oil pans), where good oil resistance and the ability to withstand large joint movements are required. Its thixotropic nature prevents it from running off the application site. Suitable for plastics or metal-plastic combinations. This silicone is not recommended for use in contact with gasoline!

Technical parameters:

• Maximum gap: 1 [mm]
• Non-sticky surface after: 40 [min]
• Curing throughout volume in 24 h: 2.75 [mm]
• Temperature resistance: -60 to +200 [°C]
• Extrusion rate: 300 [g/min]
• Shear strength: 1.2 [N/mm2]
• Elongation at break: 400 [%]
• Tensile strength: 1.7 [N/mm2]
• Shore hardness: 30 [A]

Properties:

• Chemical type: oxime silicone
• Appearance: black paste
• Components: single-component
• Viscosity: thixotropic
• Curing: vulcanization at room temperature
• Application: sealing
• Special advantage: non-corrosive
